Popis | CPU AMD Ryzen™ 7000 series Processors Single Socket LGA-1718 (Socket AM5) supported, CPU TDP supports Up to 170W TDP Core Up to 16 cores, 32 threads System Memory Memory Capacity 4 DIMM slots Memory Type 5200/4800/3600 MT/s Up to 192GB of memory with speeds of up to 5200MT/s (1DPC)/ 3600MT/s (2DPC) DIMM Sizes 8GB, 16GB, 24GB, 32GB, 48GB Memory Voltage 1.1V
Chipset B650 SATA 4 SATA3 ports; RAID 0,1,5,10 IPMI ASPEED AST2600 BMC Audio ALC 888S HD Audio Network Controllers Dual LAN with Intel® i210 Gigabit Ethernet Controller Single LAN with ASPEED AST2600 BMC, Dedicated LAN for IPMI Input / Output USB 1 USB 3.2 Gen2x2 port(s) (1 rear type C 20Gb) 5 USB 3.2 Gen2 port(s) (3 rear type A 10Gb; 2 rear type C DP 1.4 Alt mode) 2 USB 3.2 Gen1 port(s) (2 headers 5Gb) 1 USB 2 port(s) (1 via header 2 ports by a header) Video Output 1 HDMI 2.0 port(s), 1 DP 1.4a port(s), 2 rear type C port(s) DP 1.4 Alt mode Serial Port 1 COM Port(s) (1 header) TPM 1 TPM Header AOM-TPM-9670V
PCIe 1 PCIe 4.0 x4, 2 PCIe 5.0 x16 slots (16/NA or 8/8) M.2 M.2 Interface: 2 PCIe 5.0 x4, RAID 0 & 1 Form Factor: 2280/22110 Key: M-Key System BIOS BIOS Type AMI 32MB SPI Flash EEPROM |
