Stream Processors3456
Compute Units
54 CU (with RT+AI Accelerators)
Infinity Cache
48MB
Ray Accelerators54
Memory Size/Bus
12GB/192 bit GDDR6
Memory Clock
18 Gbps Effective
Displays
Maximum 4 Displays
Resolution
HDMI™: 7680×4320
DisplayPort 2.1: 7680×4320
InterfacePCI-Express 4.0 x16

Output
2x HDMI
2x DisplayPort

BIOS Support
UEFI
Game Index
1440P

Sapphire Features
Digital Power Design
Ultra High Performance Conductive Polymer Aluminum Capacitors

AMD RDNA™ 3 Architecture
54 AMD RDNA™ 3 Compute Units (with RT+AI Accelerators)
48MB AMD Infinity Cache™ Technology
DisplayPort™ 2.1Support
AMD Radiance Display™ Engine
12GB GDDR6 on 192-Bit Memory Bus
PCI® Express 4.0 ready
AMD FidelityFX™ Super Resolution technology
Microsoft® DirectX® 12 Ultimate Support
Microsoft® DirectStorage Support

2.5 slot, ATX Dimension: 280(L)X 128.75(W)X 52.57 (H)mm
Power Consumption
230W Total Board Power


Linux®, Windows® 10, and Windows 11. 64-bit operating system required

System Requirement
Minimum 700 Watt Power Supply
